Item NO. | Outer diameter | (mm) Segment height | (mm) Segment thickness | (mm) Bore diameter | |
(mm)Inch | mm | ||||
01DH-04 | 4″ | 105 | 7 | 1.7 | 20\22.23 |
01DH-045 | 4.5″ | 110 | 7 | 2.0 | 20\22.23 |
01DH-05 | 5″ | 125 | 7 | 2.0 | 20\22.23 |
01DH-06 | 6″ | 150 | 7 | 2.2 | 20\22.23 |
01DH-07 | 7″ | 180 | 7 | 2.2 | 20\22.23 |
01DH-09 | 9″ | 230 | 7 | 2.5 | 20\22.23 |
01DH-10 | 10″ | 250 | 7 | 2.5 | 22.23\25.4 |
01DH-12 | 12″ | 300 | 7 | 2.8 | 22.23\25.4\50 |
01DH-14 | 14″ | 350 | 7 | 2.8 | 25.4\50 |
01DH-16 | 16″ | 400 | 7 | 3.2 | 25.4\50 |
01DH-18 | 18″ | 450 | 7 | 3.2 | 25.4\50 |
01DH-20 | 20″ | 500 | 7 | 3.2 | 25.4\50 |
01DH-22 | 22″ | 550 | 7 | 3.2 | 25.4\50 |
01DH-24 | 24″ | 600 | 7 | 3.2 | 25.4\50 |
01DH-28 | 28″ | 700 | 8\10 | 6.5\7.5 | 50\80 |
01DH-36 | 36″ | 900 | 10 | 7.0\7.5 | 80\100 |
01DH-40 | 40″ | 1000 | 10 | 7.0\7.5 | 100 |
01DH-48 | 48″ | 1200 | 10 | 7.5\8.0 | 100 |
